UBU brand supply large Vacuum Multi-arc Ion vacuum coating machine
UBU brand large Vacuum Multi-arc Ion PVD Vacuum Coating Machineis a hightech environmental friendly product for metal,
jewellery, glass and ceramic products surface coating. After coating by this machine can improve the workpieces’ hardness, wear resistance, corrosion resistance etc.. The machine itself has many advantages such as quick pumping speed, stable vacuum environment, large load capacity and uniform coating film. Application industry including the watch industry (strap, case, dial), glass ceramics industry (glass tableware, ceramic crafts), hardware industry (sanitary ware, door knobs, locks), architecture industry (stainless steel plate, stair railings, columns), precision mold industry (standard punch mold, forming mold), tools industry (drill bits, carbide cutters, broaches, shaving heads), automotive industry (piston, piston rings, alloy wheels) as well as pens and glasses etc.. The film makes the product’s surface much more beautiful and wearable.
|Vacuum chamber size|
| Size 24403 plates|
|Vacuum pump||Diffusion pump / Molecular pump + roots pump + rotary vane pump + holding pump / Direct connect pump (can be adjusted by requested)|
Manual / PLC+touch screen
Mass flow controller(4ways),Manual or automatic processing gas system
Cooling water tower, water cycle cooling system,
From 1 atm to 2.0×10-2Patakes less than 15min (room temperature, clean and unload)
|Alarm and protection||Water pressure alarm, air pressure alarm, over current protection, execution on related protective measures and electrical interlock systems.|
|Foot print ||W3m×L3.5m||W3m×L3.5m||W3.5m×L5m||W3.5m×L5m||W4.5m×L5.5m||W5.5m×L5.5m|
|Other technical data|
Water pressure ≥0.2MPa,water temperature ≤25℃,air pressure0.5-0.8MPa
Packing and Dilivery
When you are going to send us an inquiry, in order to design the most appropriate machine for your product, please tell us some information in your letter.Thank you very much.
1, What is your products ? size ? material ?
2, How many products do you need to coating per day ?
3, What film do you want to coat on your products?
